GB/T 34107 Seamless Precision Stainless Steel Pipes For Rail Transit Vehicle Braking System
Material, Specification, Key Features
In the realm of rail transit engineering, the choice of materials is crucial to ensure the ety and efficiency of braking systems. One essential component that plays a pivotal role in this system is the seamless precision stainless steel pipe. Regulated under the esteemed GB/T 34107 standard, these pipes are designed to meet rigorous criteria for rail transit vehicles, particularly in braking applications.
Material: Stainless Steel
Specification: GB/T 34107
Key Features:
- Seamless design for enhanced strength and reliability.
- Precision engineering for optimal performance.
- Specifically tailored for rail transit vehicle braking systems.
Chemical Composition
The chemical composition of GB/T 34107 Seamless Precision Stainless Steel Pipes For Rail Transit Vehicle Braking System is detailed in the table below:
| Element | Composition (%) |
| Carbon (C) | 0.08 max |
| Silicon (Si) | 1.00 max |
| Manganese (Mn) | 2.00 max |
| Phosphorus (P) | 0.035 max |
| Sulfur (S) | 0.03 max |
| Chromium (Cr) | 17.00-19.00 |
| Nickel (Ni) | 8.00-10.00 |
Mechanical Properties
The mechanical properties of GB/T 34107 Seamless Precision Stainless Steel Pipes For Rail Transit Vehicle Braking System are presented in the table below:
| Property | Value |
| Tensile Strength | 520 MPa |
| Yield Strength | 205 MPa |
| Elongation (%) | 35% |
| Hardness (HV) | 160-190 HV |
Steel Grade and Application
Steel Grade:
The steel grade compliant with GB/T 34107 is tailored to provide optimum performance in rail transit vehicle braking systems.
Application:
These stainless steel pipes find application in rail transit vehicle braking systems, where the seamless precision design and stainless steel material characteristics are instrumental in providing durability and reliability under high-pressure braking conditions.
Possible Alternative Grades
While GB/T 34107 sets the benchmark for seamless precision stainless steel pipes, there are alternative grades that may be considered for specific applications. Some possible alternative grades include AISI 304, AISI 316, and DIN 1.4301 stainless steel pipes.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
